Model

MPW-7001-ACAAG

ATX Version

ATX 12V V2.52

PFC

Active PFC

Input Voltage

100-240V

Input Current

10-5A

Input Frequency

47-63Hz

Dimensions (L X W X H)

140 x 150 x 86 mm

Fan Size

120mm

Fan Bearing

HDB

Efficiency

≥90% @ Typical Load

80 Plus Rating

80 PLUS Gold

ERP 2014 Lot 3

Yes

Operating Temperature

0-40°C

Power Good Signal

100 - 150 ms

Hold Up Time

≥15ms at 100% load

MTBF

>100,000 Hours

Protections

OVP, UVP, OPP, OTP, SCP, OCP

Regulatory

CB, cTUVus, TUV, CE, RoHS2.0, FCC, CCC, BSMI, KC+KCC, BIS, EAC

ATX 24-Pin Connectors

1

EPS 4+4 Pin Connectors

1

EPS 8 Pin Connector

1

SATA Connectors

6

Peripheral 4-Pin Connectors

3

PCI-E 6+2 Pin Connectors

4

Series

G Series

80 Plus

Gold

Modular

Non Modular

Wattage

500 to 750W

Warranty

5 years

Note*

Price, feature and specifications are subject to change without notice
